Wallbox Supernova 150 - 150 kW Fast EV Charger

Electrical Specifications

Output Power: 150 kW
Output Voltage / Current: 150-1000V / 400 A
AC Input: 400V +/- 10%, 230A, 50-60Hz
Dynamic Power Distribution: Simultaneous charge of 2 outputs (75/75 kW down                           to 60/90 kW)
Electrical Protections: MCB, RCD Type A
Connectors: 2x CCS or CCS+CHA
Length: 3m, 5m with cable management[1]

General Specifications

Operating temperature:-30ºC to 50ºC
Storage temperature:-30ºC to 70ºC
Operational Noise Level: <65 dBA @ 1m
Protection ratings: IP54 / IK10
